铂金硫化钢丝硅胶管 SQ

应用:食品、饮料、饮用水、化妆品、制药等高洁净行业
结构:铂金硫化硅胶管,内置四层聚酯纤维布及不锈钢丝增强
温度范围:-60°C 到+200°C(+260°C可被定制)
颜色:标准为半透明,可定制其他颜色
内壁光滑,外表抗粘着性,可耐真空,可进行CIP及SIP清洗
注:如长期用于121℃以上的高温蒸汽输送,请明确告知,单独定制。
符合认证:FDA, USP, BFR, USDA, ISO 10993
长度:标准长度为4米、6米或10米

Construction: Type SQ is manufactured from High purity platinum cured Silicone with single stainless steel helix and 4 layers of polyester reinforcement.
Temp. Range: -60°C and 200°C. (+260°C on request)
Colour: Translucent (Coloured covers available)
Smooth inner and outer surface to resist material adhesion
Suitable for pressure and vacuum.
Suitable for CIP and SIP cleaning
Odourless, Tasteless, Non-Toxic
Note: If it is required to use high-temperature steam above 121 ℃ for a long time, it can be customized.
Certification: FDA, USP,BFR, USDA, ISO 10993
Length: Standard length is 4m, 6m or 10m.
** PRESSURE DECREASE BY 1% FOR EVERY 1°C ABOVE 100°C.

编码 内径 外径 弯曲半径 工作压力 爆破压力 真空度
in. mm mm mm bar bar bar
SQ006 1/4" 6.4 17 29 13 39 0.91
SQ008 5/16" 7.9 19 31 12 36 0.91
SQ010 3/8" 9.5 21 35 11 33 0.91
SQ013 1/2" 12.7 24 40 10 30 0.91
SQ016 5/8" 15.9 27 50 9 27 0.91
SQ019 3/4" 19 30 60 8.5 25.5 0.91
SQ025 1" 25.4 36 80 7.5 22.5 0.91
SQ032 1-1/4" 32 43 110 6.5 19.5 0.91
SQ038 1-1/2" 38 49 160 5.5 16.5 0.91
SQ045 1-3/4" 45 56 200 5 15 0.91
SQ051 2" 50.8 63 250 4.5 13.5 0.91
SQ064 2-1/2" 63.5 75 350 4 12 0.91
SQ076 3" 76.2 88 550 3 9 0.91
SQ089 3-1/2" 89 102 700 2.5 7.5 0.91
SQ102 4" 102 115 800 2 6 0.91
